woodworking profile sander

inner structure (9 sanding disc & 2 sanding rollers), specialize in sanding the profile surface Profile sander: 1.Both roller-type sanding and disc sanding units have oscillating function. 2.Roller-type sanding belt and disc-type sanding belt can be changed by all kinds of abrasive cloth belt, palm brush sanding belt,cotton fabric sanding belt etc. 3.Vertical travles of protect the workpiece head and tail from excessive abrasion; 4.All motors adopt independent frequency control,equipped with different sanding material to achieve different sanding appearance. 5.Suitable for sanding and polishing rugged surface. Technical data: Max working width1200 / 600 mmMin process length450mmWorking thickness20 150 mmFeeding motor1.5 kwLift table motor0.55 kwSanding motor2× 2.2 kwSanding head lift motor2× 0.12 kwOscillating motor0.25kwFeeding speed6 24 m/minSanding head rotary speed600 1500 r/minSanding disc rotary speed100-250rpmSize of sanding rollerφ250 81250 Feeding belt width1260mmWorking voltage380 V 50 HzTotal power8.81kwDimension2540 × 1860 × 2100 mmWeight2700kg
