MM-S2W6L6 edge polishing machine

Edge polishing machine It is designed for processing edge of board. Different configurations can complete different edge sandings perfectly. It is a prefect choice to reduce the labor intensity and processing procedures and replacemanual operation;Specilize in sanding and polishing the edge of the panel, both high gloss andhone finishedsurface.Belt-type pressing device with spring load is compressive and reliable and free from injury of workpiece; The pedrail adoptes chain conveying, variable speed and cylindrical guide-oriented, which is strong at feeding, stable and reliable;Angles of all kinds of milling heads and sand heads can be adjusted to complete straight-line profile sanding.The movements of sanding pad and sponge sanding head are controlled automaticially by PLC according to travel switch sensing without regulation, which greatly improves efficiency and ensures that head and tail parts of the workpiece are free from injury. SPECIFICATION working width100-1800mmMin. working length300mmMax. thickness20-80mmfeeding speed13-65m/minfeeding motor power380V,50Hz,1.5Kw,1400r/minmotor power of sanding unit2pcs, 380V,50Hz,2.2Kw,1430r/minmotor powerof tilting sanding unit2pcs, 380V,50Hz,0.12Kw,1420r/minspecification of sanding beltcircumference:2060mm width:80mmMax sanding width of sanding unit80mmLinear velocity of sanding belt8 13.5m/s(30Hz 50Hz)Tilting range of sanding unit-20° +90°Pneumatic pressure of sanding belt0.23 0.3mpaPneumatic pressure of sanding pad0.3 0.5mpaMotor power of sanding head6 pcs,380V,50Hz,2.2kw ,1420r/minMain spindle diameter of milling cutter6total power20.04kwworking voltage380V 50HzDimension8100mm*1300mm*1500mmweight3200kg
